Advantage:

● HD recording, sound quality and picture synchronization
● Dual CPU processing, powerful performance, delicate graphics, smooth operation, powerful software function
● SONY 8 million pixel high-performance photosensitive chip, low noise, high sensitivity, true color
● ARM A17 quad-core processor 2GB memory runs smoothly
● HDMI interface 4K or 2K multi-select output, adaptive 4K, 2K mode switching
● Equipped with two custom I / O
● USB2.0, USB 3.0 Gigabit network multi-select port, USB3.0 interface recording or export recording speed is faster
● Real-time status signal lamp, check the working status of the camera at any time
● The camera has a built-in image measurement system that can export EXCEL data

Feature:

● Labeling functions: Point coordinates, cross lines, coordinate systems, text annotations

● Length measurement: Line length, line length, curve length, parallel line distance, point line distance
● The center distance: The radius fixed circle, two points setting circle, three points setting circle
● Geometric measurement: Line length, radius fixed circle, two point fixed circle, three point fixed circle, concentric circles
● The geometric area: Polygon, squat
● Image fast: Support for 4K static photos
● Video video: Support 4K video

Specification:

● Image sensor: FULL HD 4K industrial camera sensor/1.25 inch
● Effective pixel: 8.3M
● Pixel size: 1.62um x 1.62um
● Frame rate: 4K 30fps@3840*2160, 1080P 60fps@1920*1080
● Output interface: 4K @60FPS HDMI output,
● The storage mode built-in 3GB memory, and support the U disk(supporting FAT32 and NTFS file system)
● Power supply: DC-12V/1A
● Thread: C mount
